The hospital beds described in this manual are constructed to the following standards: ISO9001，ISO13485,CE.

1. Designated Use

This bed is designed for positioning and transporting patients, as an aid to treating, and alleviating illnesses or compensating for injuries or disabilities.

2.Functions

       Backrest ride-up function

        Leg curving function

3. Components of the Bed

3.1 Headboards and Foot-boards

ABS blue blow molding; detachable

3.2 Side rail

Luxury four-folding concealed ABS safety side rail

3.3 Castor

125mm two-side mute castor with central brake

3.4 Chassis

The chassis consists of steel profiles, treated with electronic powder paint;

3.5 Control system

CE certified high-grade medical motor and hand controller

Storage battery

4.Specification

● Overall bed length: 2160mm

● Overall bed width: 1060mm

● Overall bed height: 450-700mm

● Mattress base length: 2000mm

● Mattress base width: 900mm

● Backrest angle: 0-75°

● Leg section angle: 0-30°

● Overall incline function: ±15°

● Bed frame on sides: Thickness:1.2mm

● Bed frame at ends: Thickness:1.2mm

● Bed leg: Thickness:1.2mm

● Bed panel：Thickness:1.0mm

● Weight capacity: 260KG

5.Limited Warranty

Applicable warranty periods commencing from date of shipment from KAIRUIJIEDE are as follows:

Welds……………………………… 1 years

Electrical components

(excluding Handset Controls)…………………………1years

Mechanical components ……………………………… 1 years

All other durable components not listed above:……1 year

Motor...................................  2years
